A Battery Charging Discharging Tester is a precision electrical testing system designed to perform controlled charge– discharge cycles on rechargeable batteries in order to evaluate their capacity, performance, efficiency, cycle life, and safety behavior. The equipment is used to simulate real-world operating conditions by applying programmable charging and discharging currents and voltages while continuously monitoring key battery parameters.
Specification/Features
- Electricity requirement 110V AC or 220V AC
- selectable for universal use
- Power Consumption 200W-5KW
- Discharge and charge Current Range availability
- Range: 6.0mA – 1000A
- Accuracy: ±(0.05% of reading + 0.1% of range)
- Discharge and charge Voltage range availability
- Range: 0.5 – 200V programmable
- Accuracy: ±(0.05% of reading + 0.1% of range)
- Data register conditions Time interval: 1 – 900s
- Max. measurement cycles 9999 cycles
- Channels
- Multi channel independent programmable channels
- Each channel can set different working modes and
- functions independently
- Battery Holders Two types of battery holders are
- included in the standard package:
- Multi alligator clips with cable for universal connecting
- Multi spring load holders with adjustable length for
- measuring cylinder battery
- Test Reports and Curves for analysis
- Different types of real time waveform, graph can be
- created by software base on user definition. (Voltage-time
- curve, current-time curve, capacity-voltage curve, loops
- times-charge/discharge capacity curve, loops times-charge/
- discharge efficiency curve, etc)
- Automatic Data reports are created by software. User can
- easily compare the performance of the batteries tested in
- channels both visually and statistically
