The Incorrect Installation Test System is a specialized safety‑testing device designed to evaluate the resilience and protection behavior of batteries, battery packs, and DC electrical systems when installed incorrectly.
Specification/Features
- Test Type Incorrect Installation / Reverse Polarity Test
- Applicable DUT Batteries, battery packs, DC modules
- Voltage Range 0 – 100 V DC
- Current Capability Up to 200 A (short‑duration)
- Polarity Switching Controlled electronic or relay‑based
- Test Duration Programmable (1 s to 9999 s)
- Voltage Accuracy ±0.05% of full scale
- Current Accuracy ±0.1% of full scale
